UNIVERSAL SYMBOLS
As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and controls.
The symbols are shown below with an indication of their meaning.
B General
Safety Alert Symbol
Master System Warning
Fast
Slow
Creep
Lock
ON (Engaged)
OFF (Disengaged)
B Engine-related
Diesel Fuel
Empty
Full
Hourmeter/Elapsed Operating Hours
Engine Coolant-Temperature
Low Temperature Reguration
Engine Intake/Combustion Air-Filter
Engine Oil-Pressure
Water Separator
Engine-Warning
Engine-Rotational Speed
Engine-Rev Limiter
Engine-Constant RPM management
Engine-RPM Increase
Engine-Run
Engine-Start
Engine-Stop
Electrical Power-accessories
Diesel Preheat/Glow Plugs
(Low Temperature Start Aid)
Emission Control
Regeneration
Regeneration inhibit
Regeneration (Switch)
Parked Regeneration
DEF/AdBlue-Level
DEF/AdBlue-Low Level
DEF/AdBlue-Poor Quality
DEF/AdBlue-Trouble
DEF/AdBlue-Freeze
B Vehicle body-related
4-Wheel Drive-On
4-Wheel Drive-Automatic
Bi-Speed turn
Auto-Transmission
Clutch
Brake
Parking Brake
Differential Lock-Front
