9. FINAL REDUCTION
9-14
DINK 125/50
Install the countershaft and gear into the
left crankcase.
Install the resin washer onto the counter-
shaft.
Install the dowel pins and a new gasket.
Install the transmission case cover.
Install and tighten the transmission case
cover bolts.
Resin Washe
r
Countershaf
t
Transmission Case Cove
r
Bolts
Dowel Pins
Gaske
t
