8-36
8.20.1. Remove
1. Make sure the ignition switch is OFF.
2. Remove the front cover ( page 8-11)
3. Release the rings and remove the rubber band (1).
4. Disconnect the negative (-) terminal lead (2) from the
battery first, and then disconnect the positive (+) terminal
lead (3).
5. Remove the battery.
8.20.2. Installation
A. Install in the reverse order of removal.
B. After installing the battery, check to see if the battery
cables are routed correctly.
NOTE
First connect the positive (+) cable and then negative (-) cable
to avoid short circuit.
(1) Positive terminal lead
(2) Negative terminal lead
(3) Rubber band
