Install the float valve, float and float pin.
Tighten the float screw securely.
FLOAT LEVEL INSPECTION
Slightly tilt the carburetor and measure the float
level with the float valve just connecting the
float arm.
Float Level: 5.0mm
Replace the float if the level is out of the
specified level range.
Install the O-ring.
Check the operation of the float and install the
float chamber.
Tighten the screws.
CARBURETOR INSTALLATION
Check the carburetor insulator and O-ring for wear
or damage.
Install the carburetor and insulator onto the intake
