connected across the horn wire terminals.
FRONT TURN SIGNAL LIGHT
REPLACEMENT
Remove the turn signal light shell and the bulb.
Replace with new ones.
TAILLIGHT/STOPLIGHT/REAR TURN
SIGNAL LIGHT BULB
REPLACEMENT
Taillight Shell Removal:
Remove two screws attaching the taillight shell.
Remove the taillight shell and stop light bulb.
Remove the rear turn signal light bulbs.
The installation sequence is the reverse of
removal.
INSTRUMENT
Instrument Bulbs Replacement
Remove the handlebar rear cover. (
ð
12-3)
Remove the bulbs and replace with new ones.
