SERVICE INFORMATION
GENERAL INSTRUCTIONS
• When working with gasoline, keep away from sparks and flames..
• Note the locations of O-rings when disassembling and replace them with new ones during
assembly.
• All cables, fuel lines and wires must be routed and secured at correct locations.
• Bleed air from the oil lines whenever they are disconnected.
SPECIFICATIONS
Venturi dia. 14mm
Identification number 0.14A
Float level 5.0mm
Main jet #80
Slow jet #35
Air screw opening 1±¼
Idle speed 2100±100rpm
Throttle grip free play 2 6mm
SPECIAL TOOL
Float level gauge
TROUBLESHOOTING
Engine does not start Lean mixture
• No fuel in tank • Clogged fuel jets • Faulty float valve
• Too much fuel getting to cylinder • Clogged fuel cap vent • Float level too low
• Clogged fuel filter • Clogged fuel filter • Clogged air cleaner
• Clogged air cleaner • Bent, kinked or restricted fuel line
Engine idles roughly, stalls or runs poorly Rich mixture
• Incorrect idle speed • Clogged air cleaner • Faulty float valve
• Ignition malfunction • Intake air leaks • Float level too high
• Compression too low • Fuel contaminated • Clogged air jets
• Incorrectly adjusted air screw • Faulty reed valve
• Incorrect float level • Clogged fuel jets
