Kyocera FS-1020D User Manual

Operator Panel
1-2
1.1 Operator Panel
The operator panel on top of the printer consists of four indicators and two
keys. The four indicators light, flash, and go off in combination, indicating
the printer’s status. The keys perform operations, such as canceling data,
switching the printer mode between online and offline status, and printing
status pages.
Figure 1-1
The numbers used in the above figure are referred to in the Reference
column of the table on the following page.
1
2
3
4
5
6
Note

Kyocera FS-1020D Specifications

General

Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Internal memory	16 MB
Processor model	Power PC 405
Built-in processor	Yes
Maximum internal memory	272 MB
Powersave acoustic emission	0 dB
Sound power level (standby)	32 dB
Sound pressure level (printing)	53 dB
I/O ports	Standard interface: High speed bi-directional parallel (IEEE 1284), USB 2.0 (Full speed), KUIO LV Option-Interface slot Multiple interface connection (MIC): MIC allows for simultaneous data transfer via up to three interfaces, with each interface having its own virtual printer.
Memory upgrade	Yes GB
Power supply type	220~240V @ 50/60Hz
Networking features	As optional: 10Base-T/100Base-TX, 10Base-FL, FibreLink, TokenRing STP/UTP, Wireless LAN - IEEE 802.11b, 10Base-T/100Base-TX/100Base-FX, FibreOptic, 10Base-2/10Base-T/100Base-TX, Optional
Standard input trays	Universal paper cassette, Multipurpose tray.
Duty cycle letter size (maximum)	15000 pages per month
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 -105 g/m2
Maximum ISO A-series paper size	A4
Maximum input capacity	250 sheets

Weight and Dimensions

Dimensions (WxDxH)	378 x 375 x 235 mm
