2LY/2LZ

2-3-1

2-3 Operati on of the PWBs

2-3-1 Power source PWB

Figure 2-3-1 Power source PWB block diagram

+5V1

SLEEP

+24V1

+24V2

FAN

+3.3V1

ZCROSS

HEATN

THERM

Power source PWB

Left

cooling

fan motor

Fuser thermistor

Fuser thermal cutout

Fuser unit

Switching

regulator

circuit

Zero cross

signal circuit

C input

Interlock

switch

Power switch

Fuser heater

lamp control

circuit

Fuser

heater lamp
