Table of Contents
1 Safety Directions 6
1.1 General Introduction 6
1.2 Denition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Electromagnetic Compatibility (EMC) 13
2 Description of the System 16
2.1 System Components 16
2.2 System Concept 16
2.2.1 Software Concept 16
2.2.2 Power Concept 17
2.2.3 Data Storage Concept 17
2.3 Container Contents 18
2.4 Instrument Components 20
3 User Interface 22
3.1 Keyboard 22
3.2 Operating Principles 24
4 Operation 25
4.1 Equipment Setup 25
4.1.1 Setting up as a Post-Processing Base 25
4.1.2 Setting up as a Real-Time Base 26
4.1.3 Setting up as a Real-Time Rover 29
4.1.4 Fixing the Field Controller to a Holder and Pole 32
4.1.5 Connecting to a Personal Computer 32
4.1.6 Connecting to the Web Server 34
4.2 Batteries 36
4.2.1 Operating Principles 36
4.2.2 Battery for GS18 37
4.3 Working with the SD Card and micro SIM Card 37
4.4 Working with the Tilt Compensation 38
4.5 Working with the GS imaging App 42
4.6 LED Indicators on GS18 45
4.7 Guidelines for Correct Results with GNSS Surveys 48
5 Care and Transport 50
5.1 Transport 50
5.2 Storage 50
5.3 Cleaning and Drying 50
6 Technical Data 52
6.1 GS18 Technical Data 52
6.1.1 Tracking Characteristics 52
6.1.2 Accuracy 52
6.1.3 Technical Data 53
6.2 Conformity to National Regulations 55
6.2.1 GS18 55
6.2.2 Dangerous Goods Regulations 59
7 Software Licence Agreement/Warranty 60
Appendix A Pin Assignments and Sockets 61
Table of Contents 5
To Next Page
