Page 3
SPECIFICATIONS
General
Model No. 14HPX−042 14HPX−048 14HPX−060
Data
Nominal Tonnage 3.5
4 5
1
Sound Rating Number 79 80 80
Connections
Liquid line o.d. − in. 3/8 3/8 3/8
(sweat)
Vapor line o.d. − in. 7/8
7/8 1-1/8
2
Refrigerant HFC−410A charge furnished 12 lbs. 7 oz. 12 lbs. 10 oz. 16 lbs. 0 oz.
Outdoor
Outer coil 24.93 24.93 29.09
Coil sq. ft.
Inner coil 24.13
24.13 28.16
Tube diameter − in. 5/16 5/16 5/16
No. of rows 2 2 2
Fins per inch 22 22 22
Outdoor
Diameter − in. 26 26 26
Fan
No. of Blades 4
4 4
Motor hp 1/3 1/3 1/3
Cfm 4347 4347 4550
Rpm 843 843 830
Watts 299 299 307
Shipping Data − lbs. 1 package 257 262 307
ELECTRICAL DATA
Line voltage data − 60 hz − 1ph 208/230V
208/230V 208/230V
3
Maximum overcurrent protection (amps) 40 50 60
4
Minimum circuit ampacity 24.2 29 34.8
Compressor
Rated Load Amps
17.94 21.79 26.41
Locked Rotor Amps
112
117 134
Power Factor
0.94 0.95 0.98
Outdoor
Full Load Amps
1.8 1.8 1.8
Fan Motor
Locked Rotor Amps
2.9
2.9 2.9
OPTIONAL ACCESSORIES − must be ordered extra
Compressor Crankcase Heater Factory S
S S
Compressor Hard Start Kit
10J42 S S
81J69 S
Compressor Low Ambient Cut−Off 45F08 S S S
Compressor Sound Cover 69J03 S S S
Freezestat
3/8 in. tubing 93G35 S S S
5/8 in. tubing 50A93 S S S
Hail Guards
27W36 S S
94M94 S
Indoor Blower Off Delay Relay 58M81 S S S
Loss of Charge Kit 84M23 S S S
5
Low Ambient Kit 54M89 S S S
Mild Weather Kit 33M07 S S S
Monitor Kit − Service Light 76F53 S S S
Mounting Base 69J07 S S S
Outdoor
Thermostat 56A87 S S S
Thermostat Kit
Mounting Box 31461 S
S S
Refrigerant
Line Sets
L15−65−30 L15−65−40
L15−65−50
S S
Field Fabricate S
Unit Stand−Off Kit 94J45 S S S
NOTE − Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Sound Rating Number rated in accordance with test conditions included in ARI Standard 270.
2
Refrigerant charge sufficient for 15 ft. length of refrigerant lines.
3
HACR type circuit breaker or fuse.
4
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
5
Crankcase Heater and Freezestat are recommended with Low Ambient Kit.
