Page 3
OPTIONS / ACCESSORIES - 092H, 102H, 120H, 150S
Item Description
Model
Number
Catalog
Number
Unit Model No
092 102 120 150
CONTROLS
Blower Proving Switch C1SNSR35FF1 53W65 OX OX OX OX
Commercial Controls L Connection
®
Building Automation System - - - X X X X
Prodigy
®
Control System - BACnet
®
Module - C0CTRL60AE1L 59W51 OX OX OX OX
Prodigy
®
Control System - LonTalk
®
Module - C0CTRL65FF1 54W27 OX OX OX OX
Novar
®
ETM-2051 - E0CTRL30B1
64W73 OX OX OX OX
Novar
®
LSE
Factory O O O O
Dirty Filter Switch E1SNSR55B-1 53W67 OX OX OX OX
Fresh Air Tempering C1SNSR75AD1 58W63 OX OX OX OX
Smoke Detector - Supply or Return (Power board and one sensor) C1SNSR44B-2 11K76 OX OX OX OX
Smoke Detector - Supply and Return (Power board and two sensors) C1SNSR43B-2 11K80 OX OX OX OX
INDOOR AIR QUALITY
Air Filters
High Efciency Air Filters
20 x 25 x 2 (Order 4 per unit)
MERV 8 - C1FLTR15B-1 50W61 OX OX OX OX
MERV 13 - C1FLTR40B-1 52W41 OX OX OX OX
Replacement Media Filter With Metal Mesh
Frame (includes non-pleated lter media)
C1FLTR30B-1- Y3063 X X X X
Indoor Air Quality (CO
2
) Sensors
Sensor - Wall-mount, off-white plastic cover with LCD display C0SNSR50AE1L 77N39 X X X X
Sensor - Wall-mount, off-white plastic cover, no display C0SNSR52AE1L 87N53 X X X X
Sensor - Black plastic case with LCD display, rated for plenum
mounting
C0SNSR51AE1L 87N52 X X X X
Sensor - Wall-mount, black plastic case, no display, rated for
plenum mounting
C0MISC19AE1 87N54 X X X X
CO
2
Sensor Duct Mounting Kit - for downow applications C0MISC19AE1- 85L43 X X X X
Aspiration Box - for duct mounting non-plenum rated CO
2
sensors
(87N53 or 77N39)
C0MISC16AE1- 90N43 X X X X
UVC Germicidal Lamps
1
UVC Light Kit (208/230v-1ph) C1UVCL10B-1 54W62 OX OX OX OX
ELECTRICAL
Voltage 60 hz 208/230V - 3 phase Factory O O O O
460V - 3 phase Factory O O O O
575V - 3 phase Factory O O O O
HACR Circuit Breakers Factory O O O O
Disconnect Switch 80 amp - C1DISC080B-1 54W56 OX OX OX OX
150 amp - C1DISC150B-1 54W57 OX OX OX OX
GFI Service
Outlets
15 amp non-powered, eld-wired (208/230V, 460V only) LTAGFIK10/15 74M70 OX OX OX OX
20 amp non-powered, eld-wired (575V only) C1GFCI20FF1 67E01
OX OX OX OX
Weatherproof Cover for GFI C1GFCI99FF1 10C89 X X X X
Phase/Voltage Detection (Optional for CAV options only, furnished with staged blower option) Factory O O O O
ECONOMIZER
Standard Economizer (Not for Title 24)
Standard Economizer
Downow or Horizontal - Includes Outdoor Air Hood and Downow
Barometric Relief Dampers with Exhaust Hood
Order Horizontal Barometric Relief Dampers separately
E1ECON15B-1 55W05 OX OX OX OX
High Performance Economizer (Approved for California Title 24 Building Standards)
High Performance Economizer
Downow or Horizontal - Includes Outdoor Air Hood and Downow
Barometric Relief Dampers with Exhaust Hood
Order Horizontal Barometric Relief Dampers separately
E1ECON17B-1 10U59 OX OX OX OX
Horizontal Barometric Relief Dampers
Horizontal Low Prole Barometric With Exhaust Hood LAGEDH03/15 53K04 X X X X
Economizer Controls (Not for Title 24)
Differential Enthalpy Order 2 - C1SNSR64FF1 53W64 OX OX OX OX
Sensible Control Sensor is Furnished Factory O O O O
Single Enthalpy C1SNSR64FF1 53W64 OX OX OX OX
Global Control Sensor Field Provided Factory O O O O
1
Lamps operate on 110-230V single-phase power supply. Step-down transformer may be ordered separately for 460V and 575V units. Alternately, 110V power supply
may be used to directly power the UVC ballast(s)
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed
