5
XC25
Typical Unit Parts Arrangement
GROUND LUGS
OUTDOOR
CONTROL
INVERTER REACTOR,
230V, 4KW
DC INVERTER
CONTROL
CONTACTOR-SPST
(25FLA/35RES)
GROUND LUGS
CONTACTOR-SPST
(35FLA/40RES)
OUTDOOR CONTROL
INVERTER NOISE FILTER FOR
6KW INVERTER (208/240V,
60HZ, CURRENT RANGE 30A
MAXIMUM, INDUCTANCE
4.3MH)
INVERTER REACTOR,
230V, 6KW
CONTROL PANEL FOR
XC25-024 AND -036
CONTROL PANEL FOR
XC25-048 AND -060
DC INVERTER
CONTROL
Figure 1. Control Panel Components
