Lenovo B8080 Hardware Maintenance Manual
3. Detach the rear camera from its seat on the left speaker box by inserting a thin
flat blade under the camera bottom.
Figure 9-3. Detaching the rear camera
4. Remove the rear camera from the tablet.
Figure 9-4. The removed rear camera
54

Lenovo B8080 Specifications

General

Resolution	1280 x 800 pixels
Processor	Qualcomm Snapdragon 400
RAM	1 GB
Internal Storage	16 GB
Rear Camera	5 MP
Front Camera	1.6 MP
Model	Lenovo B8080
Number of Cores	4
Pixel Density	189 ppi
Display Technology	IPS LCD
Bluetooth	4.0
GPS	Yes
Card Slot	microSD, up to 64 GB
Display Size	8.0 inches
CPU	ARM Cortex-A7
Display Resolution	1280 x 800
Wi-Fi	802.11 b/g/n
Dimensions	8.9 mm
Operating System	Android 4.4.2 KitKat
