Lenovo ThinkPad T490 Hardware Maintenance Manual

When the power is turned on, the computer returns from hibernation mode and resumes operation. The
hibernation file in the boot record on the hard disk drive or solid-state drive is read, and system status is
restored from the hard disk drive or solid-state drive.
Symptom-to-FRU index
This section contains following information:
• “Numeric error codes” on page 37
• “Error messages” on page 39
• “Beep errors” on page 39
• “No-beep symptoms” on page 41
• “LCD-related symptoms” on page 41
• “Intermittent problems” on page 42
• “Undetermined problems” on page 42
The symptom-to-FRU index in this section lists symptoms and errors and their possible causes. The most
likely cause is listed first, in boldface type.
Note: Do the FRU replacement or other actions in the sequence shown in the column headed “FRU or
action, in sequence.” If replacing a FRU does not solve the problem, put the original part back in the
computer. Do not replace a nondefective FRU.
This index can also help you determine, during regular servicing, what FRUs are likely to need to be replaced
next.
A numeric error is displayed for each error detected in POST or system operation. In the displays, n can be
any number.
If no numeric code is displayed, check the narrative descriptions of symptoms. If the symptom is not
described there, go to “Intermittent problems” on page 42.
Note: For a device not supported by diagnostic codes in the ThinkPad notebooks, see the manual for that
device.
Numeric error codes
Table 2. Numeric error codes
Symptom or error (beeps, if any)
FRU or action, in sequence
0177
Bad SVP data, stop POST task—The checksum of the
supervisor password in the EEPROM is not correct.
Replace the system board.
0183
Bad CRC of Security Settings in EFI Variable. Enter the
ThinkPad Setup program. – The checksum of the Security
settings in the EFI Variable is not correct.
1. Run the ThinkPad Setup program. The settings
will be corrected automatically. Then save the
current settings by pressing F10.
2. Replace the system board.
0187
EAIA data access error - The access to EEPROM is failed.
Replace the system board.
0188
Invalid RFID Serialization Information Area.
Replace the system board.
0189
Invalid RFID configuration information area - The
EEPROM checksum is not correct.
Replace the system board.
Chapter 4. Related service information 37

Lenovo ThinkPad T490 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black
Market positioning	Business
LED backlight	Yes
Display diagonal	14 \
Bus type	OPI
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i5-8265U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1528
Processor threads	8
Processor codename	Whiskey Lake
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	1.8 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Internal memory	8 GB
Memory clock speed	2400 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
On-board graphics card ID	0x3EA0
Discrete graphics card model	Not available
On-board graphics card family	Intel® UHD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Number of built-in speakers	2
Antenna type	-
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	100, 1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Keyboard layout	QWERTY
Pointing device	Touchpad
Number of battery cells	3
AC adapter power	65 W
Processor ARK ID	149088
Processor package size	46x24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	227 mm
Width	329 mm
Height	17.9 mm
Weight	1460 g
