Electrical installation
Parallel connection
Braking units with brake resistor
5
l
41
EDBMB935X EN 8.0
( Stop!
Correct synchronisation of braking units connected in parallel:
ƒ Set switching thresholds of all braking units to the same value
(see chapter 5.3.9).
ƒ Connect synchronisation interfaces correctly
– Output: A1, A2 / input E1, E2
– For total lengths £ 0.5 m you do not have to use shields.
ƒ Configuring braking units with switch S3 as master and slave:
– Configure the first braking unit in the interconnection as
master (S3 = OFF).
– Configure each further braking unit within the interconnection
as slave (S3 = ON).
