Diagnostics
Diagnostics with Global Drive Oscilloscope (GDO)
10
226
EDBCSXS064 EN 4.0
10.2 Diagnostics with Global Drive Oscilloscope (GDO)
The "Global Drive Oscilloscope" (GDO) is included in the scope of supply of the Lenze
parameter setting and operating program "Global Drive Control" (GDC) and the "Drive PLC
Developer Studio" (DDS) and can be used as an additional diagnostic program.
The GDO serves to record e.g. input and output data and device−internal states during
controller operation.
Note!
ƒ Detailed information concerning the handling and functional range of GDO
can be gathered from the Manual "Global Drive Oscilloscope (GDO), First
steps".
ƒ Overview of the variables used in the GDO: 428
ECSXA480
Fig. 10−3 Global Drive Oscilloscope (GDO)
Menu bar
Symbol bar at the top
Data sets
Symbol bar on the left
Graph display field
Vertical operating elements
Status display
Trigger/cursor operating elements
Horizontal operating elements
Operating elements for recording
