Lenze i510 Series Commissioning

11.16 UPS operaon
This funcon enables the operaon of a 3x400-V inverter with an uninterrupble 1x230-V
power supply (UPD) to be able to operate the motor with reduced load for a certain period in
the event of a power failure.
NOTICE
UPS operaon is not suitable for a connuous operaon.
Possible consequence: Device overload
▶
Prevent a too frequent use of this funcon.
Restricons
•
UPS operaon is only available for 3x400-V devices up to 11 kW.
•
For UPS operaon, one reduced output current and one reduced overload are available
only:
•
Output current: 60 % of the 400-V rated current
•
Overload: 80 %/5 min, 120 %/3 s of the 400-V rated current
•
In order to change over to UPS operaon, a minimum delay of 10 s is required.
Details
The following gure shows the principal connecon of the UPS to the inverter. For further
technical details, please contact the inverter manufacturer.
GND AI1 AI2 AO1
10V 24V DI1 DI2 DI3 DI4 DI5 DO1
X3
F1
…
F3
Q1
3/N/ 400 VPE AC
3/ PE
340 V ... 528 VAC
45 Hz ... 65 Hz
N
L3
L2
L1
L1 L2 L3
X100
PE
N
L1
F4
Q2
F5
USP Power supply
1/N/ 230 VPE AC
PE
Q3
t
Q1
t
Q2
t
Q3
①
A mutual locking is required for the contactors Q1 and Q2.
②
In this example, the digital input DI5 is used to acvate the UPS operaon. For this purpose, the funcon "Acvate UPS operaon"
0x2631:055 (P400.55) must be assigned to trigger "Digital input 5 [15]".
③
In order to change over to UPS operaon, a minimum delay of 10 s is required.
The UPS operaon can be alternavely acvated via network. In this case, a bit of the mappa-
ble data word NetWordIN1 0x4008:001 (P590.01) must be assigned to the "Acvate UPS oper-
aon [55]" funcon.
Addional funcons
UPS operaon
318

Lenze i510 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Dimensions	Varies by model
Weight	Varies by model
Control Type	V/f control, vector control
Communication Interfaces	CANopen, Modbus RTU, EtherCAT, PROFIBUS, PROFINET
Ambient Temperature	-10°C to +50°C
Braking Resistor	Optional
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Output Voltage	0 to input voltage
Input Voltage	200-240 V, 380-480 V
Voltage Range	200-240 V, 380-480 V
Frequency Range	0 to 599 Hz
