Parameter Name / value range / [default seng] Info
0x2348:002
(P516.02)
PROFIBUS Status: Watchdog status
(PROFIBUS Status: Watchdog status)
•
Read only
Display of the current state of the watchdog state machine (WD-STATE).
0 BAUD_SEARCH The inverter (slave) is able to detect the baud rate automacally.
1 BAUD_CONTROL Aer detecng the correct baud rate, the inverter (slave) status changes
to BAUD_CONTROL, and the baud rate is monitored.
2 DP_CONTROL The DP_CONTROL state serves to the response monitoring of the master.
0x2349
(P517.00)
PROFIBUS error
(PROFIBUS error)
•
Read only
Bit-coded display of PROFIBUS errors.
Bit 0 Watchdog elapsed Communicaon with the PROFIBUS master is connuously interrupted,
e. g. by cable break or failure of the PROFIBUS master.
•
No process data are sent to the inverter (slave) in the "Data Exchange"
state.
•
When the watchdog monitoring me specied by the master has
elapsed, the response set in 0x2859:001 (P515.01) is triggered in the
inverter.
Precondions for a response by the inverter (slave):
•
The slave is in the "Data Exchange" state.
•
The watchdog monitoring me is congured correctly in the master
(1 ... 65535 ms).
If one of these precondions is not met, the response to the absence of
cyclic process data telegrams from the master is not executed.
Bit 1 Data exchange completed Data exchange via PROFIBUS has been terminated.
•
The inverter (slave) can be instructed by the master to exit the "Data
Exchange" state.
•
If this state change is to be treated as an error in the inverter, the
desired response can be set in 0x2859:002 (P515.02).
Bit 2 Incorrect conguraon data The inverter (slave) has received invalid conguraon data from the
master.
•
The response set in 0x2859:003 (P515.03) is eected.
Bit 3 Inialisaon error An error has occurred during the inialisaon of the PROFIBUS interface.
•
The response set in 0x2859:004 (P515.04) is eected.
Bit 4 Invalid process data The inverter (slave) has received invalid process data from the master,
e.g. no process data or deleted process data are sent by the "Stop" oper-
ang status in the master.
•
The response set in 0x2859:005 (P515.05) is eected.
0x2859:001
(P515.01)
PROFIBUS monitoring: Watchdog elapsed
(PROFIBUS monit.: WD elapsed)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response to the connuous interrupon of communica-
on to the PROFIBUS master, e. g. by cable break or failure of the PROFI-
BUS master.
Associated error code:
•
33168 | 0x8190 - Network: watchdog meout
2 Trouble
0x2859:002
(P515.02)
PROFIBUS monitoring: Data exchange exited
(PROFIBUS monit.: Data exch.exited)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response to exing the "Data Exchange" state.
Associated error code:
•
33169 | 0x8191 - Network: disrupon of cyclic data exchange
0 No response
0x2859:003
(P515.03)
PROFIBUS monitoring: Invalid conguraon
(PROFIBUS monit.: Invalid cong)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the recepon of invalid congura-
on data.
Associated error code:
•
33414 | 0x8286 - Network: PDO mapping error
2 Trouble
0x2859:004
(P515.04)
PROFIBUS monitoring: Inialisaon error
(PROFIBUS monit.: Init. error)
•
For further possible sengs, see parameter
0x2D45:001 (P310.01). ^ 223
Selecon of the response triggered by the occurrence of an error during
the inialisaon of the PROFIBUS module.
Associated error code:
•
33170 | 0x8192 - Network: inialisaon error
2 Trouble
Conguring the network
PROFIBUS
Monitoring
297
