Power supply modules
Rated data
Overview
5
242
EDS94SPP101 EN 10.2
5.3 Rated data
5.3.1 Overview
Input data
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C up to +55 °C
E94APNE0104 230/400/480 50/60 8/8/8 6/6/6 3
E94APNE0364 230/400/480 50/60 29/29/29 21.8/21.8/21.8 3
E94APNE1004 230/400/480 50/60 82/82/82 61/61/61 3
E94APNE2454 230/400/480 50/60 200/200/200 150/150/150 3
Temperature in the control cabinet
Output data
Voltage Frequency Current [A]
Number of
phases
Type [V] [Hz] up to +45 °C
up to +55 °C
E94APNE0104 325/565/675 0 (DC) 10/10/10 7.5/7.5/7.5 −
E94APNE0364 325/565/675 0 (DC) 36/36/36 27/27/27 −
E94APNE1004 325/565/675 0 (DC) 100/100/100 75/75/75 −
E94APNE2454 325/565/675 0 (DC) 245/245/245 184/184/184 −
Temperature in the control cabinet
