Lenze L-force 9400 Hardware Manual

Power supply modules
Rated data
Operation with rated mains voltage 480 V
5

247
EDS94SPP101 EN 10.2
5.3.4 Operation with rated mains voltage 480 V
Input data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f [Hz]
3/PE AC 480 340 − 0 % ... 528 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Continuous input power
Type [V] S
L
[kVA]
E94APNE0104 480 6.6
E94APNE0364 480 24.1
E94APNE1004 480 68.1
E94APNE2454 480 166
Output data
Mains Volta
g
e Volta
g
e ran
g
e Fre
q
uenc
y
ran
g
e
Voltage
U
DC
[V]
Voltage
range
U
DC
[V]
Frequency
range
f [Hz]
2/PE DC 675 480 − 0 % ... 746 + 0 % −
Output current and output power
100 % 5−s cycle 3−min cycle
Type I
DC
[A] P
DC
[kW] I
DC
[A] P
DC
[kW] I
DC
[A] P
DC
[kW]
E94APNE0104 10 4.3 40 17.2 15 6.5
E94APNE0104
+ E94AZMP0084
10 5.8 40 23.3 15 8.7
E94APNE0364 36 15.6 108 48.8 54 23.4
E94APNE0364
+ E94AZMP0294
36 21.0 108 63.0 54 31.5
E94APNE1004 100 43.4 200 86.8 150 65.1
E94APNE100
+ E94AZMP0824
100 58.3 200 117 150 87.5
E94APNE2454 245 106 368 159 368 159
E94APNE2454
+ E94AZMP2004
245 143 368 215 368 215
100 % Permanent rated values
5−s cycle Cycle for the second−range
(0.5 s overload/4.5 s recovery time with 75 % of the permanent rated value)
3−min cycle Cycle for the minute−range
(60 s overload/120 s recovery time with 75 % of the permanent rated value)
