Power supply modules
Rated data
Mains filters for power supply modules
5
251
EDS94SPP101 EN 10.2
5.3.6 Mains filters for power supply modules
When using the mains filters assigned, conditions must be observed for compliance with
EMC class C2:
ƒ The measures for the use on IT systems must be applied to all axis modules in the
interconnection (separation of internal filter components from PE, ( 355)).
ƒ The maximum sum total of all motor cable lengths ( l
mot
) for the filter used must
be observed.
Motor cable lengths in the interconnection
The assigned filters are designed for l
mot
(E94AZRPxxx4: 60 m (= 6 x 10 m), E94AZMPxxx4: 500 m (= 10 x 50 m)).
For a different number of axis modules, l
mot
can be determined from the following
diagrams.
Maximum total of motor cable lengths [m] for the achievement of EMC Category C2
Number of axes Power supply module with
RFI filter E94AZRPxxx4
(short distance)
Mains filter E94AZMPxxx4
(long distance)
1 67.5 100
2 67.5 200
3 67.5 300
4 65 400
5 62.5 500
6 60 600
7 57.5 575
8 55 550
9 52.5 525
10 50 500
11 47.5 475
12 45 450
13 42.5 425
14 40 400
15 37.5 375
16 35 350
17 32.5 325
18 30 300
19 27.5 275
20 25 250
