SF staple operation
1 Staple unit
2 Sensor (staple throat paper present)
For staple jobs, the paddles push the paper stack to the rear of the finisher.
The sensor (staple throat paper present) detects the paper stack. The staple unit holds down and staples the
paper stack.
4064
Theory of operation
921
