12
ENG
ENGLISH
Pivot Feature
1
Raise the monitor to the maximum height.
2
Adjust the angle of the monitor in the direction
of the arrow as shown in the figure.
3
Rotate the monitor 90° clockwise and -90°
counter clockwise as shown in the figure.
4
Complete the installation by rotating the
monitor 90° clockwise and -90° counter
clockwise as shown below.
NOTE
y
Auto Pivot feature of the display is not sup-
ported.
y
The screen can be rotated easily using the
screen pivot shortcut key provided with your
Windows operating system. Note that some
Windows versions and some graphics card
drivers may use different settings for the screen
pivot key or may not support the pivot key at all.
y
Windows screen pivot shortcut keys
-
0°: Ctrl + Alt + Up arrow key (↑)
-
90°: Ctrl + Alt + Left arrow key (←)
-
180°: Ctrl + Alt + Down arrow key (↓)
-
270°: Ctrl + Alt + Right arrow key (→)
y
To avoid scratching the stand base, make sure
that when rotating the monitor using the pivot
feature, the stand does not make contact with
the monitor.
Stand
Stand
Head
Head
WARNING
The pivot feature allows the monitor to rotate 90°
clockwise and -90° counter clockwise.
To Next Page
