LG 24BL650C-B User Manual

6
ENGLISH
Pivot Feature
The pivot feature allows the monitor to rotate 90° clockwise.
Head
Stand
WARNING
• To avoid scratching the stand base, make sure that when rotating the monitor using the pivot feature, the
stand does not make contact with the monitor.
1 Raise the monitor to the maximum height.
2 Adjust the angle of the monitor in the direction of the arrow as shown in the figure.
3 Rotate the monitor clockwise as shown in the figure.
4 Complete the installation by rotating the monitor 90° as shown below.
NOTE
• Auto Pivot feature of the display is not supported.
• The screen can be rotated easily using the screen pivot shortcut key provided with your Windows operating
system. Note that some Windows versions and some graphics card drivers may use different settings for the
screen pivot key or may not support the pivot key at all.

LG 24BL650C-B Specifications

General

3D	No
Screen shape	Flat
Display surface	Matt
Display diagonal	23.8 \
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	75 Hz
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Flicker-free technology	Yes
RMS rated power	2.4 W
Number of speakers	2
Product color	Black
Market positioning	Business
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
VGA (D-Sub) ports quantity	0
Pivot angle	-90 - 90 °
Cable lock slot	-
Tilt angle range	-5 - 35 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Cables included	AC, HDMI
Power cable length	1.5 m
Package type	Box
Sustainability certificates	RoHS, EPEAT Bronze
Harmonized System (HS) code	85285210

Weight and Dimensions

Weight (with stand)	5300 g
Width (without stand)	- mm
Weight (without stand)	- g
