LG 32LE2R User Manual

- 26 -
DATE: 2006. 10. 31.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1000 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1001 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%
C1002 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1003 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%
C1004 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1006 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1007 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%
C1009 0CE107WF6DC MVK6.3TP16VC100M 100uF 20%
C1011 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1012 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1013 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1014 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1015 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1016 0CE477EJ618 KMG5.0TP35VB470M 470uF 20%
C1017 0CE477WF6DC MVK10TP16VC470M 470uF 20%
C1018 0CE227WF6DC MVK8.0TP16VC220M 220uF 20%
C1019 0CE477WF6DC MVK10TP16VC470M 470uF 20%
C1020 0CE477EJ618 KMG5.0TP35VB470M 470uF 20%
C1021 0CE227WF6DC MVK8.0TP16VC220M 220uF 20%
C1022 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1023 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1024 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1025 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1026 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1027 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1029 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1031 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1036 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1037 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1038 0CE477WF6DC MVK10TP16VC470M 470uF 20% 16
C1039 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1040 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C1043 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1045 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1046 0CE477WF6DC MVK10TP16VC470M 470uF 20% 16
C1047 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1048 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1050 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1051 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1052 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1054 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1056 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1057 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1058 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1059 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1061 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1063 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1064 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1065 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1066 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1068 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C1070 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
DATE: 2006. 10. 31.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1072 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C1073 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C1074 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C111 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C112 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C113 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C114 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C115 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C116 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C117 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C118 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 1
C119 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 1
C120 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C124 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 1
C125 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% 1
C126 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V
C128 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V
C131 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C134 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V
C135 0CE106WH6DC MVK5.0TP25VC10M 10uF 20% 25V
C137 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C138 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C141 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C142 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C163 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C164 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C172 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50
C173 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50
C174 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50
C175 0CK682CK51A C1608Y5P1H682KT 6.8nF 10% 50
C309 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C310 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C311 0CC470CK41A C1608C0G1H470JT 47pF 5% 50V
C312 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C313 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C316 0CC120CK41A C1608C0G1H120JT 12pF 5% 50V
C317 0CC120CK41A C1608C0G1H120JT 12pF 5% 50V
C332 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C333 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C334 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C335 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C336 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C337 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C339 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C340 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% 1
C343 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C345 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16V
C347 0CK104CF56A 0603B104K160CT 100nF 10% 16V
C350 0CK103CK56A 0603B103K500CT 10nF 10% 50V
C351 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C352 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C400 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C401 0CE476WF6DC MVK6.3TP16VC47M 47uF 20% 16V
C406 0CK104CK56A 0603B104K500CT 100nF 10% 50V
REPLACEMENT PARTS LIST
MAIN BOARD
CAPACITOR
For Capacitor & Resistors, the
charactors at 2nd and 3rd digit in the
P/No. means as follows;
CC, CX, CK, CN, CH : Ceramic
CQ : Polyestor
CE : Electrolytic
CF : Fixed Film
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RH : CHIP, Metal Glazed(Chip)
RR : Drawing
