3-41 3-42
MAIN
33P, 1.25mm
10P, 1mm
6P, 3.96mm
15P, 2.5mm
MD
10P, 1.25mm
FRONT FRONT_CTRL
6P, 2mm
6P, 2mm
SMPS
6P, 3.96mm
15P, 2.5mm
VFD
Portable MIC
33P, 1.25mm
10P, 1.25mm
Harness
FFC
WIRING DIAGRAM
