LG DLE2515S User Manual

36
1.
Disassemble the top plate.
2.
Remove the Cover Cabinet.
3.
Remove the filter and 2 screws.
4.
Remove the air duct.
1.
Disassemble the top plate.
2.
Remove the Cover Cabinet and Tub Drum [Front].
3.
Remove the Drum assembly and Tub Drum [Rear].
4.
Disconnect the Air duct from the Tub Drum [Front].
5.
Remove the roller from the Tub Drum [Front]
and Tub Drum [Rear].
