26
Disassemble and repair the unit only after pulling out power plug from the outlet.
DISASSEMBLY INSTRUCTIONS
11
1.
Remove 3 screws on the rear Panel.
2.
Pull the control panel forward.
3.
Open the cover protect.
4.
Disconnect connectors.
5.
Remove 5 screws.
6.
Disassemble the controller assembly.
