30 Room Air Conditioner

Replacement Parts List

LWHD1807HR LWHD2400HRY7

130410 BASE ASSEMBLY,SINGLE 3041A23004F 3041A23004H R

130910 CABINET ASSEMBLY,SINGLE 3091AR6056Q 3091AR6056Q R

135314 GRILLE ASSEMBLY,INLET 3530AR1604A 3530AR1604A R

135312 GRILLE ASSEMBLY,FRONT(SINGLE) 3531A20073W 3531A20073W R

135510 COVER ASSEMBLY,CONTROL 3551A30015A 3551A30015A R

137215 PANEL,CONTROL 3720AR6163A 3720AR6163A R

146812 MOTOR ASSEMBLY,SYNC 2H01102J 2H01102J R

147581-1 LOUVER,HORIZONTAL 4758AR7264C 4758AR7264C R

147581-2 LOUVER,HORIZONTAL 4758AR7278C 4758AR7278C R

147582 LOUVER,VERTICAL 4758AR6157A 4758AR6157B R

148000 BRACE 4800AR7271A 4800AR7271A R

149980 SHROUD 4998AR1597B 4998AR1597B R

159830 FILTER(MECH),A/C 5231AR6159A 5231AR6159A R

238310 ESCUTCHEON 3831A10018M 3831A10018M R

249950 CONTROLBOXA SSEMBLY,SINGLE 4995A20186F 4995A20186G R

264110 POWERCORD ASSEMBLY 6411A20056Q 6411A20056Q R

567480 THERMISTOR ASSEMBLY 6323A20003S 6323A20003S R

268711-1 PWB(PCB)ASSEMBLY,DISPLAY 6871A20611V 6871A20611V R

268711-2 PWB(PCB)ASSEMBLY,MAIN(AC) EBR30851603 EBR30851603 R

267110 REMOTE CONTROLLER 6711A20034D 6711A20034D R

346811 MOTOR ASSEMBLY,AC 4681A20081T 4681A20130E R

349001 DAMPER,VENTILATION 4900AR7265A 4900AR7265A R

349600 MOUNT,MOTOR 4960AR1596A 4960A10006A R

352111 TUBEA SSEMBLY,CONNECTOR 5211AR7059A 5211AR3399Z R

352113 TUBE ASSEMBLY,DISCHARGESINGLE 5211A25040C 5211A21526V R

35211A TUBE ASSEMBLY,SUCTIONSINGLE 5211A20204G 5211A30250H R

749750 AIRGUIDE ASSEMBLY 5239A20001N 5239A20001N R

354210 EVAPORATOR ASSEMBLY,FIRST 5421A20059F 5421A20248E R

359012 FAN ASSEMBLY,BLOWER 5834AR1599B 5834AR1599B R

550140 ISOLATOR,COMP 4H00982C 4022U-L005A R

552102 TUBE,CAPILLARY 5421AP3074X 5211A21444C R

554031 CONDENSER ASSEMBLY,Bending 5403A20062F 5403A20232G R

554160 COMPRESSOR 2520UCBJ002 5416A20045B R

559011 FAN ASSEMBLY,AXIAL 5900AR1508B 5900AR1508B R

753000 HEATER,ELECTRIC 5300A20003A 5300A20003A R

753010 HEATER ASSEMBLY,ELECTRIC 5301A30001B 5301A30001B R

W0CZZ CAPACITOR,DRAWING 6120AR2194F 0CZZA20001X R

W48602 CLAMP,SPRING 3H02932C 3H02932C R

325115-1 TUBE,EVAPORATOR 5211A20433C 5210A22224W R

325115-2 TUBE,EVAPORATOR 5211A20433D 5210A22224U R

LOCATION

NO.

DESCRIPTION

PART NO(2007)

REMARK

135500 COVER 3550AR6173A R

731273 INSTALL PART ASSEMBLY,SINGLE 3127A10015M R

749740 GUIDE 2H00858D R

135515 COVER ASSEMBLY,TOP(INDOOR) 3551A30001A R

3550AR6173A

3127A10015M

2H00858D

3551A30001A
