APPENDIX
■
The specifications shown above may be changed without prior notice for quality improvement.
Power
AC100-240V~ 50/60 Hz 0.6A
On Mode : 35W (typ.)
Sleep Mode 1W
Off Mode 0.5 W
LCD Panel
Screen Type
Pixel Pitch
18.51 inches Wide (470.1mm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 470.1mm
0.30(H) x 0.30(V) mm
Max. Resolution
Recommended Resolution
Horizontal Frequency
Vertical Frequency
Synchronization Type
Video Signal
1360 X 768 @60 Hz
1360 X 768 @60 Hz
30 - 61 kHz
56 - 75 Hz
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART*2, PC Audio In, component, DVI-D, HDMI*2, CVBS
Rated Voltage
Power Consumption
Tilt
Tilt Range
-5 ~ 15
°
Dimensions (Width x Height x Depth)
Weight
449.7 x 368.8 x 221.6 mm (17.70 x 14.52 x 8.72 inches)
3.88 kg / 8.55 lbs
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
10 ~ 35°C
20 ~ 80%
-10 ~ 60°C
5 ~ 90%
PRODUCT SPECIFICATIONS
<<MM11996622DD>>

LG M2762D Specifications

General

Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	16:9
Display diagonal	27 \
Separate H/V sync	Yes
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	584.2 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Bandwidth	0.135 GHz
Display viewable area (HxV)	597.7 x 336.2 mm
Display resolution at frequency	1920 x 1080 @ 60 Hz
USB hub version	2.0
RMS rated power	6 W
Certification	TÜV-Typ, CE, UL, CSA, SEMKO, FCC-B
Product color	Black
Market positioning	-
Compliance industry standards	DDC 2B
LED indicators	Stand-by
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	120 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	210 mm
Width (without stand)	654.1 mm
Height (without stand)	494.6 mm
Weight (without stand)	8920 g
