5 Appendix
Appendix 41
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption Refer to the main label on the unit.
Dimensions (W x H x D) Approx. 451.5 mm x 317.0 mm x 305.5 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs / Output
Analog audio in (AUX IN) 600 mV, 600 Ω, RCA jack (L, R) x 1
Analog audio out (AUX OUT) 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 80 to 18,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 220 W RMS (3 Ω at 1 kHz, 25 % THD)
y Design and specications are subject to change without notice .
