HSLG Slide Gate Operator Installation Guide - 29 - P1220 Revision X8 6-22-2011
MODEL HSLG MECHANICAL PARTS LIST
REF. # PART # DESCRIPTION
2110-240
Intermediate Shaft Assembly
10 2100-765 Pulley Shaft
14 2200-213 Sprocket, 41-B-9, 5/8” bore
9 2200-309 Double Pulley, 7”
11 2200-233 Set Collar Set, 5/8”
92 2200-215 Precision Bearing, 5/8”
72 2200-333 Key, 3/16” x 1-1/2”
71 2100-1750 Key, 3/16” x 1-1/4”
12 2100-547 Brake Disc
2110-274
Clutch Shaft Assembly
30 2100-1008 Clutch Shaft
28 2200-294 Sprocket, 41-A-36, 1” bore
31 2100-669 Clutch Hub (pinned)
78 2100-1007 Clutch Hub (keyed)
79 2100-564 Clutch Facing
32 2200-306 Clutch Spring
33 2400-061 Hex Nut, 5/8”-18
89 2400-062 Jam Nut, 5/8”-18
81 2400-187 Thrust Washer, 1” x 1/8”
2400-088 Roll Pin, 3/16” x 1-3/8”
27 2200-292 Sprocket, 41-B-12, 5/8” bore
2200-215 Precision Bearing, 5/8”
11 2200-233 Set Collar, 5/8”
70 2400-238 Key, 3/16” x 1-1/4”
82 2400-273 Key, 3/16” x 1/4”
2110-236
Output Shaft Assembly
15 2100-917 Output Shaft, 1”
20 2220-022 Sprocket, 41-A-24 with Bearing
93 2200-119 Bearing only for 41-A-24 Sprocket
21 2110-131 Shifter Block with Pins
25 2200-274 Pillow Block Bearing, 1”
97 2100-1737 Pillow Block Retaining Plate
37 2200-014 Set Collar, 1” x 3/8” LTB
26 2200-091 Set Collar, 1” x 5/8” LTB
73 2400-201 Key, 1/4” x 1-1/2”
16 2200-968 Sprocket, 40-B-22, 1” bore
2400-026 Spring Pin, 3/16” x 1” (Predrilled for Pillow Block)
18 2110-700 Idler Assembly
6 2520-173R
Rotary Limit Box Assembly
2500-764 Limit Switch
2100-057 Standard Limit Shaft
2200-030 Limit Nut
2100-261 Detent Plate
2110-162 Limit Box Enclosure with Cover
2100-756 Limit Box Cover only
2200-029 Flange Bearing, 1/2” ID
2200-193 E-Ring, 1/2”
2400-203 Spring Washer, 1/2”
7 2200-008 Limit Drive Sprocket, 48-B-10, 1/2” bore
For Drives up to 30 feet wide:
2200-008 Limit Box Sprocket, 48-B-10, 1/2” bore
2200-654 #48 Chain, per foot, 27 Links required
For Drives from 31 to 45 feet wide:
2200-041 Limit Box Sprocket, 48-B-15, 1/2” bore
2200-654 #48 Chain, per foot, 29 Links required
For Drives over 45 feet wide:
2200-276 Limit Box Sprocket, 48-B-20, 1/2” bore
2200-654 #48 Chain, per foot, 30 Links required
34 2200-202 #40 Chain, per foot
36 2400-038 U-Bolt, 4-5/8”
REF. # PART # DESCRIPTION
MOTORS
95
2500-2307 1/2 HP, 115 VAC, 1 Phase
2500-2308 1/2 HP, 208/230 VAC, 1 Phase
2500-2309 3/4 HP, 115 VAC, 1 Phase
2500-2310 3/4 HP, 208/230 VAC, 1 Phase
2500-2311 1 HP, 115 VAC, 1 Phase
2500-2312 1 HP, 208/230 VAC, 1 Phase
2500-2313 1/2 HP, 208/230/460V, 3 Phase
2500-2314 3/4 HP, 208/230/460V, 3 Phase
2500-2315 1 HP, 208/230/460V, 3 Phase
CAPACITORS
2500-2336 Capacitor for 2500-2307 Motor
2500-2337 Capacitor for 2500-2308 Motor
2500-1926 Capacitor #1 for 2500-2309 Motor
2500-1930 Capacitor #2 for 2500-2309 Motor
2500-1931 Capacitor for 2500-2310 Motor
2500-2338 Capacitor for 2500-2311 Motor
2500-1932 Capacitor for 2500-2312 Motor
MAGNETIC BRAKES (INCLUDES 41, 42, 44, 45 AND 46)
40 2510-398 115V
2510-399 230V
2510-400 460V
41 2220-983 Brake and Puck Assembly
42 2500-177 Brake Solenoid, 230 VAC
2500-178 Brake Solenoid, 115 VAC
2500-1351 Brake Solenoid, 460 VAC
44 2200-243 Brake Spring (short)
46 2100-548 Brake Rod
45 2100-541 Brake Plate
13 2100-2091 Bracket for Brake
1 2120-359-BT Enclosure Assembly Complete with Door
2120-360-BT Door Assembly only
2300-716 Stop/Reset Button Cover
2110-643 Lock Assembly with Keys
2200-540 Replacement Key
53 2110-234 Rail Assembly
3 2100-573 Spacer Plate
94 2200-207 Double Pulley, 2”
29 2400-149 Chain, #41, 30 Links
22 2120-132 Shifter Lever
23 2100-910 Locking Disconnect Lever
24 2200-291 Disconnect Spring
19 2100-657-BT Rain Cover
75 2400-088 Roll Pin
87 2100-2007 Gate Bracket
88 2400-170 U-Bolt, 3”
84 2100-258 Chain Tension Bolt, 1/2”
85 2200-306 Clutch/Chain Tension Spring
86 2400-090 Hex Nut, 1/2”-13 (4)
2400-045 Flat Washer, 1/2”
5 2200-234 V-Belt, 28”
2100-553 Bearing Spacer
90 2200-150 #41 Chain, per foot (20 links required)
76 2200-027 #41 Master Link
2100-656-BT Side Plate, 1/2”
2100-059-BT Side Plate, 3/16”
96 2200-006 #40 Master Link
8 2200-654 #48 Chain, per foot (27 links required)
77 2200-010 #48 Master Link
91 2400-422 5/16-18 U-Nut (4)
100 2510-248 Stop/Reset Button and Bracket Assembly
2100-1760 Stop/Reset Button Mounting Bracket
2500-1495 Stop/Reset Button
