9
4. Take off the middle hinge by removing
the screws. Lift the lower door and place
it on a padded surface to prevent it from
scratching.
5. Remove the lower screws, hinge bracket
and adjustable feet from the unit bottom.
Keep the matching bracket and foot
together.
unscrew
6. Remove the remaining screw-type
adjustable foot from the other side of
the unit bottom and transfer it to the
corresponding position on the opposite
side of the unit bottom.
7. Reattach the bottom door hinge, screws
and foot to the opposite side of the unit.
unscrew unscrew
unscrew
screw
180˚
