Lumiax MT2010 Connection Manual

DEFAULT CONFIGURATION IN TRACKSO IOT GATEWAY
Inverter ID: 1, 2, 3, 4 …. Continuous numbering starting with 1, (Range: 1 to 247)
Baud Rate: 9600 (Default) (Values: 9600, 19200, 38400)
Data Bits: 8 , Stop Bit: 1 , Parity: None
CONFIGURATION AT THE CONTROLLER END
Charge Controller is available at Id,1 and baud rate-9600bps and protocol – Modbus RTU by default.
NOTE: The above details are mentioned in the Installation & Operation Manual for Lumiax Solar Charge
Controller

Lumiax MT2010 Specifications

General

Model	MT2010
System Voltage	12V/24V Auto
Rated Charge Current	10A
Max. PV Input Voltage	50V
Max. PV Input Power (12V)	130W
Max. PV Input Power (24V)	260W
Operating Temperature	-35°C to +55°C
Self-consumption	<10mA
