FEARLESS1000 part list
Capacitor CD110-50V-1µF 2 E2.5-5 2 C308 C316
CD110-50V-10µF 5 E2.5-5 5 C309 C311 C312 C120 C101
CD110-50V-22µF 2 E2.5-6.5 2 C419 C420
CD110-50V-47µF 2 E2.5-6.5 2 C415 C417
CD110-100V-47µF 2 E5-10 2 C413 C414
CD110-50V-100µF 1 E5-8 1 C201
CD110-16V-220µF 1 E2.5-6.5 1 C307
Capacitor CD110-50V-220µF 1 E5-10 1 C203
Capacitor CD263-25V-220µF-105℃(Φ8×11.5) 1 E5-8 1 C302
Capacitor CD11K-25V-2200µF-105℃ 6 E5-13 6 C306 C305 C303 C304 C317 C318
(Φ12.5×25) (golden yellow color)
Capacitor CD293-100V-2200µF(Φ30×30) 6 E10-30 6 C408 C411 C407 C409 C412 C410
(golden yellow color)
Diode 1N4004 3 D10 3 D210 D209 D303
1N4148 16 D6 7 D307 D304 D305 D407 D408 D404 D403
D8 1 D306
D10 8 D208 D207 D206 D205 D204 D203 D202 D201
Diode 1N5402 2 D15 2 D301 D302
Regulator diode 1N4744A (15V) 2 ZD10 2 ZD5 ZD6
Opposite vertex diode U1620R 2 TR2 2 DL1 DL2
Opposite vertex diode U1620 2 TR2 2 DL3 DL4
Light-emitting diode LED(red/Φ3) 1 LED1 1 PRO
Light-emitting diode LED(green/Φ3) 1 LED1 1 POW
Audion A1013 1 TR1 1 Q302
A1015 5 TR1 5 Q303 Q402 Q404 Q403 Q401
A1268 5 TR1 5 Q207 Q205 Q206 Q202A Q202B
A1376 1 TR1 1 Q212
A1381 1 TR2-T 1 Q209
A1837 1 TR2-T 1 Q215
A1941 5 TR3 5 Q218 Q219 Q220 Q221 Q222
B817 1 TR3 1 Q217
C1567-R 1 TR2 1 Q211
C1815 3 TR1 3 Q301 Q304 Q305
