Makita 9911 Technical Information

Repair
(1) Replacing of armature
1) Loosen the tapping screw PT4 x25 for mounting the
housing R to remove the housing R, and the fan 60 for
cooling the motor will be exposed.
2) Loosen the tapping screw PT4 x25 for mounting the belt
cover to remove the belt cover.
3) Disconnect the holder cap and then remove the carbon
brush.
4) Remove the synchro belt 6-300 and steel plate.
Housing R
Tapping screw
PT4x25(7 pieces)
Tapping screw
PT4x25(4 pieces)
Belt cover
Fan 60

Makita 9911 Specifications

General

Power	650 W
Dust container type	Dust bag
Type of sander	Belt sander
Dust extraction port	Yes
Power source	AC

Weight and Dimensions

Depth	262 mm
Width	130 mm
Weight	2700 g
