184
ENGLISH
No. Part name QTY
001 HEX SOCKET HEAD BOLT M6x90 4
002 SPRING WASHER 6 4
003 FLAT WASHER 6 4
004 CYLINDER HEAD L 1
005 HEAD GASKET L 1
006 VALVE PLATE L COMPLETE 1
007 OUTLET VALVE 2
008 INLET VALVE 2
009 CYLINDER GASKET L 1
010 CYLINDER L (50Hz) 1
011 ELBOW 8-R1/4 4
012 RING 8 4
013 RING NUT 8 4
014 ELBOW 10-R3/8 1
015 RING 10 1
016 RING NUT 10 1
017 CONNECTING ROD L ASSEMBLY 1
018 SHEET RING L 1
019 LEAF SPRING L 1
020 WEAR RING L 1
021 HEX NUT M18 1
022 CONED DISC SPRING 18 1
023 BALANCER (50Hz) 1
024 SPACER 3
025 CRANK SPACER L 1
026 CRANK SPACER H 1
027 + PAN HEAD SCREW M5x16 3
028 FLAT WASHER 5 3
029 + TAPPING SCREW 4x18 3
030 FILTER COVER 1
031 FILTER 1
032 CRANK CASE COVER 1
033 O-RING 147 1
034 CONNECTING ROD H ASSEMBLY 1
035 SHEET RING H 1
036 LEAF SPRING H 1
037 WEAR RING H 1
038 PIPE 8 1
039 HEX SOCKET HEAD BOLT M8x70 4
040 SPRING WASHER 8 4
041 FLAT WASHER 8 4
042 CYLINDER HEAD H 1
043 HEAD GASKET H 1
044 VALVE PLATE H COMPLETE 1
045 CYLINDER GASKET H 1
046 CYLINDER H (50Hz) 1
047 STAFFING L 1
048 STAFFING H 1
049 HEX NUT M8 1
050 CAPACITOR RUN 1
051 HEX SOCKET HEAD BOLT M6x40 8
052 FLAT WASHER 6 4
053 SLEEVE 6 4
054 CUSHION 4
055 CRANK CASE 1
056 BALL BEARING 6305LLB 1
057 BEARING RETAINER 1
058 COUNTERSUNK HEAD SCREW M5x12 3
059 STATOR 1
060 KEY 6 1
061 ROTOR 1
062 BALL BEARING 6303LLB 1
063 O-RING 49 1
064 REAR BRACKET 1
065 FLAT WASSHER 5 4
066 SPRING WASHER 5 4
067 HEX BOLT M5x150 4
068 FAN 195 1
069 RETAINING RING 14 1
070 MOTOR COVER B 1
071 BUSHING 1
072 THERMAL CIRCUIT BREAKER 1
073 MOTOR COVER C 1
074 POWER SUPPLY CORD 1
075 CORD 1
076 CORD CRAMP 2
077 SWICH ASSEMBLY 1
078 RING NUT 6 1
079 PIPE 6 1
080 BARREL NIPPLE R1/4-30 1
081 CHECK VALVE 1
082 RING 6 1
083 RING NUT 6 1
To Next Page
