Makita DF330DWE User Manual

2
1
2
Fig.1
1
Fig.2
1
Fig.3
A
B
1
Fig.4
1
Fig.5
3
1
2
Fig.6
1
Fig.7
Fig.8

Makita DF330DWE Specifications

General

Number of gears	2
Torque settings	19
Chuck capacity (max)	10 mm
Chuck capacity (min)	0.8 mm
Screw diameter (max)	5.1 mm
Sound pressure level	70 dB
Idle speed (1st gear)	350 RPM
Idle speed (2nd gear)	1300 RPM
Sound level uncertainty	3 dB
Drilling diameter in wood (max)	21 mm
Maximum torque (hard applications)	24 N⋅m
Maximum torque (soft applications)	14 N⋅m
Reverse	Yes
Chuck type	Keyless
Product design	Pistol grip drill
Power source	Battery
Charging time	50 min
Battery voltage	10.8 V
Battery capacity	1.3 Ah

Weight and Dimensions

Depth	189 mm
Width	53 mm
Height	183 mm
Weight	1000 g
