7
For European countries
When lowering the handle, the blade guard A rises automatically. The blade
guard B rises as it contacts a workpiece. The guards are spring loaded so it
returns to its original position when the cut is completed and the handle is
raised. NEVER DEFEAT OR REMOVE THE BLADE GUARDS OR THE
SPRING WHICH ATTACHES TO THE GUARD.
In the interest of your personal safety, always maintain each blade guard in
good condition. Any irregular operation of the blade guards should be cor-
rected immediately. Check to assure spring loaded return action of guards.
NEVER USE THE TOOL IF THE BLADE GUARDS OR SPRING ARE DAM-
AGED, FAULTY OR REMOVED. DOING SO IS HIGHLY DANGEROUS AND
CAN CAUSE SERIOUS PERSONAL INJURY.
If the see-through blade guard becomes dirty, or sawdust adheres to it in such
a way that the blade is no longer easily visible, unplug the saw and clean the
guard carefully with a damp cloth. Do not use solvents or any petroleum-based
cleaners on the plastic guard.
If the blade guard is especially dirty and vision through the guard is impaired,
use the supplied socket wrench to loosen the hex bolt holding the center cover.
Loosen the hex bolt by turning it counterclockwise and raise the blade guard
and center cover. With the blade guard so positioned, cleaning can be more
completely and efficiently accomplished. When cleaning is complete, reverse
procedure above and secure bolt. Do not remove spring holding blade guard.
If guard becomes discolored through age or UV light exposure, contact a Mak-
ita service center for a new guard. DO NOT DEFEAT OR REMOVE GUARD.
1. Blade guard A
2. Blade guard B
(For European countries)
1
2
006661
1. Blade guard B
(For European countries)
1
001782
