1 Standard equipment

Abrasive cut-off wheel 355

Socket wrench 17 (for LW1401 only)

Note: The standard equipment may vary by country or model variation.

2 Optional accessory

Abrasive cut-off wheel 355

3 Index

1 Standard equipment ............................................................................................................................................................. 2

2 Optional accessory .............................................................................................................................................................. 2

3 Index .................................................................................................................................................................................... 2

4 Caution ................................................................................................................................................................................ 2

5 Repair .................................................................................................................................................................................. 3

5-1 NECESSARY REPAIRING TOOLS ......................................................................................................................... 3

5-2 LUBRICANT AND ADHESIVE APPLICATION .................................................................................................... 4

5-3 DISASSEMBLY/ASSEMBLY................................................................................................................................... 5

5-3-1 Armature ............................................................................................................................................................. 5

5-3-2 Handle section .................................................................................................................................................... 5

5-3-3 Helical gear 50 .................................................................................................................................................... 6

5-3-4 Vise Section ........................................................................................................................................................ 8

5-3-5 Guide plate .......................................................................................................................................................... 9

5-3-6 Main frame, Base and others ............................................................................................................................ 11

6 Circuit diagram .................................................................................................................................................................. 13

7 Wiring diagram.................................................................................................................................................................. 14

4 Caution

Repair the machine in accordance with “Instruction manual” or “Safety instructions

Follow the instructions described below in advance before repairing:

· Wear gloves.

· Remove Abrasive cut-off wheel.

· When the engine is hot from use, cool down the engine enough or you can get burned.

· In order to avoid wrong reassembly, draw or write down where and how the parts are assembled, and what are the parts.

· It is also recommended to have boxes ready to keep disassembled parts by group.

· Handle the disassembled parts carefully.

· If some bolts and screws are too tight, use an impact driver.

· Tighten the bolts and the screws to the specified torque.
