Explanation of general view
1-1. Bit protrusion
1-2. Base
1-3. Nut
1-4. Scale
1-5. Adjusting screw
2-1. Wing bolt
2-2. Graduation
2-3. Wing nut
2-4. Trimmer shoe
2-5. Amount of chamfering
2-6. Base
3-1. Switch lever
4-1. Loosen
4-2. Tighten
4-3. Hold
5-1. Wing nut
5-2. Spring washer
5-3. Base
5-4. Trimmer shoe
5-5. Flat washer
5-6. Bolt
6-1. Trimmer shoe
6-2. Base
7-1. Feed direction
7-2. Bit revolving direction
7-3. Workpiece
7-4. Straight guide
9-1. Screws
9-2. Wing bolt
9-3. Base
9-4. Screwdriver
10-1. Template guide
10-2. Base
10-3. Convex portions
11-1. Straight bit
11-2. Base
11-3. Templet
11-4. Distance (X)
11-5. Workpiece
11-6. Templet guide 10
13-1. Bolt
13-2. Guide plate
13-3. Straight guide
13-4. Wing nut
14-1. Clamp screw (A)
14-2. Straight guide
14-3. Wing nut
14-4. Base
14-5. Wing bolt
16-1. Wing nut
16-2. Guide plate
16-3. Straight guide
16-4. Center hole
16-5. Bolt
17-1. Wing nut
17-2. Guide plate
17-3. Straight guide
17-4. Center hole
17-5. Bolt
18-1. Nail
18-2. Center hole
18-3. Straight guide
20-1. Clamp screw (A)
20-2. Adjusting screw
20-3. Clamp screw (B)
20-4. Trimmer guide
20-5. Wing bolt
21-1. Workpiece
21-2. Bit
21-3. Guide roller
22-1. Limit mark
23-1. Brush holder cap
23-2. Screwdriver
SPECIFICATIONS
Model 3710
Collet chuck capacity 6 mm or 1/4"
No load speed (min
-1
) 30,000
Overall length 302 mm
Net weight 1.6 kg
Safetu class /II
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE010-1
Intended use
The tool is intended for flush trimming and profiling of
wood, plastic and similar materials.
ENF002-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated in accordance with European
Standard and can, therefore, also be used from sockets
without earth wire.
ENG104-2
Noise
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (L
pA
) : 80 dB(A)
Uncertainty (K) : 3 dB(A)
The noise level under working may exceed 80 dB (A).
Wear ear protection.
ENG224-2
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode : rotation without load
Vibration emission (a
h
) : 2.5 m/s
2
or less
Uncertainty (K) : 1.5 m/s
2
ENG901-1
•
The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
