Manitowoc SD0453W User Manual

262 Part Number 80-1479-3 7/10
S1800 Remote Air-cooled Condenser
All Remote Condenser Air-cooled with a Manufacture
Date Before 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to 70/21 8.9-9.8 10.0-11.0 10.7-11.7
1 - 2.5
80/27 9.0-9.9 10.1-11.1 10.8-11.9
90/32 9.2-10.1 10.1-11.1 10.8-11.9
100/38 9.6-10.5 10.0-11.0 11.6-12.7
110/43 10.4-11.5 11.5-12.6 12.5-13.7
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 13 - 14.125 lb
2 Ratings with JC1395 condenser
50/10 70/21 90/32
-20/-29 to 70/21 1800 1630 1540
80/27 1780 1620 1520
90/32 1750 1610 1520
100/38 1690 1630 1430
110/43 1570 1440 1340
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
220-250 44-26 110-170 65-85
70/21 240-280 50-28 115-180 70-90
80/27 245-290 50-28 115-180 70-90
90/32 250-300 52-28 120-195 70-90
100/38 260-340 60-28 125-210 70-90
110/43 295-390 60-30 125-220 80-100
