Manitowoc SD0453W User Manual

264 Part Number 80-1479-3 7/10
SY1894N
Half Dice Cube, Remote Condenser Air-cooled with a
Manufacture Date After 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to 70/21 9.2-10.5 10.0-11.4 10.8-12.2
1 - 2.5
80/27 9.6-10.9 10.4-11.8 11.2-12.7
90/32 10.2-11.6 10.8-12.3 11.7-13.3
100/38 10.8-12.2 11.5-13.1 12.5-14.2
110/43 11.8-13.4 12.7-14.4 13.8-15.7
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 13 - 14.125 lb
2 Ratings with JC1395 condenser
50/10 70/21 90/32
-20/-29 to 70/21 1770 1650 1550
80/27 1720 1600 1500
90/32 1630 1540 1440
100/38 1550 1460 1360
110/43 1430 1340 1240
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
230-265 38-24 100-160 70-85
70/21 240-265 40-26 110-170 70-90
80/27 250-275 45-28 110-180 70-95
90/32 250-300 52-29 110-180 70-95
100/38 275-335 55-31 110-185 75-100
110/43 310-385 55-32 120-190 80-110
