OWNER’S MANUAL
ILLUSTRATED
PARTS LIST
For Solenoid and Control Board
Assemblies and Mounting
This list contains replaceable parts used in
your generator. When ordering parts, fol-
low the instructions listed under Replace-
ment Parts on page 32 of this manual.
* Model MGH10000A Only
† All Models Except MGH10000A
KEY PART
NO.
NUMBER
DESCRIPTION QTY.
1 100105-01 Control Board Assembly 1
2 26499000 Hex Head Screw, 10-32 x 3/4" 4
3 100321-01 Nylon Spacer 4
4 WP-C3 Flat Washer, #10 4
5 26514000 Lock Nut, 10-32 4
6 100324-03 Solenoid Assembly (Includes
Plunger, Nut, and Lock Washer) 1
7 103812-01 Retaining Ring* 1
8 100755-02 Linkage Rod* 1
100755-01 Linkage Rod 1
9 22822000 Roll Pin 1
10 102939-01 Solenoid Mounting Bracket* 1
100756-01 Solenoid Mounting Bracket 1
11 103811-01 Nylon Washer* 1
12 100328-01 Bolt, M8 x 25mm
†
1
13 02407002 Flat Washer, 5/16"
†
1
14 100329-01 Lock Nut, M8
†
1
PARTS AVAILABLE NOT SHOWN
100320-01 Yellow Wire 1
100322-01 White Wire (with 2 Flags) 1
100322-02 White Wire (with 1 Flag and 1 Spade) 1
100366-01 Rocker Switch 1
100334-01 Auto-Idle Decal 1
