2023 OWNER’S MANUAL
/
86
X AND XT SERIES
DUAL SCREEN DASH
OPERATION
We continually strive to bring you the highest quality, full-featured products. As a result, you may find that your
actual display screens may be slightly dierent than what is represented in this manual at the time of printing.
The Dual Screen Dash is designed for instrumentation and control on electronically controlled engines
communicating via CAN networks. The Dual Screen Dash is made up of two screens, one 10.1” touchscreen
(PV1100) and one 12.3” non-touch display (PV1200). The 12.3” PV1200 screen displays information based on the
operating mode of the boat. The 10.1” PV1100 touchscreen is the command center for all of the boat’s systems.
