2023 OWNER’S MANUAL
/
242
ATTITUDE ADJUSTMENT PLATE
Models
Standard on the X24, X26, and XStar. XT Series and NXT models,
as an option.
Purpose
When used properly, the plate improves the ride, reduces drag,
increases speed, and improves the fuel eciency of the boat
Location
The attitude adjustment plate is permanently attached to the
boat’s stern, below the waterline. The operator may control the
plate using either the video display (as explained more fully in
the Video Display Gauges section of this Owner’s Manual) or by
manual switches located on the driver’s armrest.
Operation
The operation of the attitude adjustment plate is basic. The plate
is mounted with an actuator on the transom of the boat. When the
plate is lowered, the water flow is redirected, creating an upward
force at the boat’s stern. When the stern rises, the bow will lower.
Since these actuators are electro-hydraulic, they provide an
immediate response at the touch of the helm mounted switch.
(The attitude adjustment plate can also be controlled through the
dual screen and 7” touchscreen dash.) Press and hold UP on the
switch raise the center tab. Press and hold DOWN on the switch to
lower the center tab into the water.
Because our models have dierent weights, lengths, speed
and performance, it will take some practice for the operator to
understand how the boat reacts with the attitude adjustment plate
installed. The plate will allow your boat to get on plane faster and
continue planing at lower speeds. It improves visibility and the
overall safety of your boat.
When making adjustments with the attitude adjustment plate, use
short momentary taps of the switch. Continued practice will help
you become familiar with how the plate performs.
Special Attention
Because these plates can adversely aect boat handling if not
utilized properly, the following information is provided to assist
operators in determining the correct usage of the attitude
adjustment plate(s).
Special Conditions
Head Sea: Lower the plate by tapping slightly on BOW DOWN on a
single system. This will bring the bow down while maintaining speed.
This also allows the boat hull to absorb wave impact.
This adjustment will result in a more ecient and smoother ride.
Changes should be made in small increments to ensure maintaining
control of the boat.
