2023 OWNER’S MANUAL
/
70
XT24
FEATURES
01. Bow cleat
02. Navigation light
03. Anchor storage
04. Horn
05. Ballast tank below deck
06. ZeroO GPS puck
07. Bow sub-woofer
08. Bilge thru-hull
09. Ballast thru-hull vent
10. Midship cleat
11. Circuit breaker panel
12. Instrument panel
13. Steering wheel
14. Throttle control and emergency stop
switch
15. Fire suppression unit manual override
16. Sub-woofer (where equipped)
17. Heated seat
18. Pop up rear-facing backrest
19. Wireless cockpit chargers (where
equipped)
20. Cooler (under seat)
21. Convertible center rear seating (where
equipped)
22. Ballast thru-hull outlet
23. Stern cleat
24. Fuel tank fill
25. Engine flush valve
26. Engine compartment
27. Bilge thru-hull outlet
28. Automatic fire extinguisher
29. Transom remote (where equipped)
30. Underwater lights (two, where
equipped)
31. Surf tab (one on each side and in
center)
32. Center surf tab
33. Navigation light
34. Bow filler cushion (where equipped)
35. Amp
36. Bow sub-woofer
37. Trash can door
38. Handheld fire extinguisher
39. Glove box
40. Observer remote (where equipped)
41. Center drain plug
42. Heated observer seat (where
equipped)
43. Batteries ON-OFF switch
44. Pop up rear-facing backrest
45. Tower with clamping board racks
46. Anchor light and tower tow point
attachment
47. Pylon attachment
48. Batteries (under seat)
49. Ballast thru-hull vents
50. Sun deck flip seating (where equipped)
51. Transom drain plug
52. Swim platform
SPECIFICATIONS
Length of Boat 24’ 0”
Width Amidship 86.5”
Boat Weight 5,550 lbs.
Length of Boat w/ Platform 26’
Towing Length 29’ 11”
Towing Width 102”
Fuel Capacity 92 G
Maximum Capacity 17 people
or 2,500 lbs.
Bow: 5 people or 750 lbs.
Weight must be evenly distributed.
