22
FRANÇAIS
Z12x8
Z08x8
Z04x4
Z07x8
Z10x4
Z07x8
Z11x 8
Z09x2
Z07x2
Z07x4
Z11x4
2
Pièces de fixation Qté
Z09
Z07
Z11
Boulon (M10x75L)
Rondelle plate (M10x25L)
Boulon (M10x30L)
2
14
12
MONTAGE
1
Pièces de fixation Qté
Z08
Z07
Z10
Z04
Z12
Boulon (M10x25L)
Rondelle plate (M10x25L)
Boulon (M10x105L)
Écrou (M10)
Rondelle plate (M10x19L)
8
8
4
4
8
LE MONTAGE EST TERMINÉ
