carefully prying on the edge of the lens
unit with the flathead screwdriver.
2. Disconnect the electrical connector
from the bulb by pressing the tab on
the connector with your finger and
pulling the connector.
CAUTION
When replacing the bulb always
disconnect the connector rst.
Otherwise, electric and electronic
devices could be shorted.
3. Insert the flathead screwdriver into the
gap between the lens and the lens unit,
and then slide the screwdriver to
detach the lens.
4. Disconnect the bulb by pulling it out.
5. Install the new bulb in the reverse
order of the removal procedure.
Maintenance and Care
Owner Maintenance
6-45
CX-9_8JK1-EA-20G_Edition2_old 2020-7-20 17:31:45
