J3 CONN 3 POS M MTS100 NRML 117214
J4 CONN 2 POS RIGHT ANGLE 117274
J5 BLADE FASTON W/FEET 117708
J6 BLADE FASTON W/FEET 117708
Q8 TRANS NPN THERMLTRAK 132300
Q9 TRANS PNP THERMLTRAK 132301
Q10 TRANS NPN THERMLTRAK 132300
Q11 TRANS PNP THERMLTRAK 132301
Q12 TRANS NPN THERMLTRAK 132300
Q13 TRANS PNP THERMLTRAK 132301
Q14 TRANS NPN THERMLTRAK 132300
Q15 TRANS PNP THERMLTRAK 132301
Q16 TRANS NPN THERMLTRAK 132300
Q17 TRANS PNP THERMLTRAK 132301
Q18 TRANS NPN THERMLTRAK 132300
Q19 TRANS PNP THERMLTRAK 132301
R1 RES MF 1K 1% 1/4W 144090
R2 RES MF 2.21 OHM 1% 1/4W 144378
R3 RES MF 1K 1% 1/4W 144090
R4 RES MF 2.21 OHM 1% 1/4W 144378
R5 RES MF 2.21 OHM 1% 1/4W 144378
R6 RES MF 2.21 OHM 1% 1/4W 144378
R7 RES MET OX 47 OHM .5W 5% 137096
R12 RES WW .68 OHM 5W 5% 139245
R13 RES WW .68 OHM 5W 5% 139245
R14 RES WW .68 OHM 5W 5% 139245
R15 RES WW .68 OHM 5W 5% 139245
R16 RES WW .68 OHM 5W 5% 139245
R17 RES WW .68 OHM 5W 5% 139245
R18 RES WW .68 OHM 5W 5% 139245
R19 RES WW .68 OHM 5W 5% 139245
R20 RES WW .68 OHM 5W 5% 139245
R21 RES WW .68 OHM 5W 5% 139245
R22 RES WW .68 OHM 5W 5% 139245
R23 RES WW .68 OHM 5W 5% 139245
RT1 SENSOR THERMAL 144249
CAPACITOR PCB 050217
C2 CAP MONO .01UF 50V 20% X7R 061304
C3 CAP ELECT 47UF 35V 066446
C4 CAP ELECT 47UF 35V 066446
C5 CAP MONO .01UF 50V 20% X7R 061304
C8 CAP DISC MONO .47UF 50V 061249
C10 CAP POLYPROP 1uF 160V 5% 064451
C11 CAP POLYPROP 1uF 160V 5% 064451
D1 DIODE SILICON 070047
D2 DIODE SILICON 070047
D3 DIODE SILICON 070047
D4 DIODE SILICON 070047
D5 DIODE SILICON 070047
D6 DIODE SILICON 070047
D7 DIODE SILICON 070047
GP1 STANDOFF 6-32 X 1/4 PCB MNT 112130
GP2 STANDOFF 6-32 X 1/4 PCB MNT 112130
GP3 STANDOFF 6-32 X 1/4 PCB MNT 112130
GP4 STANDOFF 6-32 X 1/4 PCB MNT 112130
HS1 HEATSINK 018787
J1 CONN 8 POS M FRICTION LOCK 117275
J2 BLADE FASTON W/FEET 117708
J3 CONN 3 POS M MTS100 NRML 117214
J4 CONN 2 POS RIGHT ANGLE 117274
J5 BLADE FASTON W/FEET 117708
J6 BLADE FASTON W/FEET 117708
Q2 TRANSISTOR NPN SILICON 132171
Q3 TRANSISTOR PNP SILICON 132172
Q6 TRANSISTOR MJE15032 NPN 132288
Q7 TRANSISTOR MJE15033 PNP 132289
Q8 TRANS NPN THERMLTRAK 132300
Q9 TRANS PNP THERMLTRAK 132301
Q10 TRANS NPN THERMLTRAK 132300
Q11 TRANS PNP THERMALTRAK 132301
Q12 TRANS NPN THERMALTRAK 132300
Q13 TRANS PNP THERMLTRAK 132301
Q14 TRANS NPN THERMLTRAK 132300
Q15 TRANS PNP THERMLTRAK 132301
Q16 TRANS NPN THERMLTRAK 132300
Q17 TRANS PNP THERMLTRAK 132301
Q18 TRANS NPN THERMLTRAK 132300
Q19 TRANS PNP THERMLTRAK 132301
R1 RES MF 1K 1% 1/4W 144090
R2 RES MF 2.21 OHM 1% 1/4W 144378
R3 RES MF 1K 1% 1/4W 144090
R4 RES MET OX 220 OHM .5W 5% 137097
R5 RES MET OX 220 OHM .5W 5% 137097
R6 RES MF 22.1K 1% 1/4W 144187
R7 RES MF 22.1K 1% 1/4W 144187
R8 RES MET OX 680 OHM .5W 5% 137093
R9 RES MET OX 680 OHM .5W 5% 137093
R11 RES MET OX 47 OHM .5W 5% 137096
R12 RES WW .68 OHM 5W 5% 139245
R13 RES WW .68 OHM 5W 5% 139245
R14 RES WW .68 OHM 5W 5% 139245
R15 RES WW .68 OHM 5W 5% 139245
R16 RES WW .68 OHM 5W 5% 139245
R17 RES WW .68 OHM 5W 5% 139245
R18 RES WW .68 OHM 5W 5% 139245
R19 RES WW .68 OHM 5W 5% 139245
R20 RES WW .68 OHM 5W 5% 139245
R21 RES WW .68 OHM 5W 5% 139245
R22 RES WW .68 OHM 5W 5% 139245
R23 RES WW .68 OHM 5W 5% 139245
R25 RES MF 2.21 OHM 1% 1/4W 144378
R26 RES MF 2.21 OHM 1% 1/4W 144378
R27 RES MF 2.21 OHM 1% 1/4W 144378
RT1 SENSOR THERMAL 144249
LOGO AND LOGOB PCB 050218
DS1 LED GR 5MM HI-INT VF[V] 3.5 058165
DS2 LED GR 5MM HI-INT VF[V] 3.5 058165
DS3 LED GR 5MM HI-INT VF[V] 3.5 058165
DS4 LED GR 5MM HI-INT VF[V] 3.5 058165
DS5 LED GR 5MM HI-INT VF[V] 3.5 058165
DS6 LED GR 5MM HI-INT VF[V] 3.5 058165
DS7 LED GR 5MM HI-INT VF[V] 3.5 058165
DS8 LED GR 5MM HI-INT VF[V] 3.5 058165
DS9 LED GR 5MM HI-INT VF[V] 3.5 058165
J1 CONN 4 PIN 117215
J2 CONN 3 POS M MTS100 NRML 117214
J5 CONN 3 POS M MTS100 NRML 117214
R1 RES MF 1.65K 1% 1/4W 144093
R2 RES MF 1.65K 1% 1/4W 144093
R3 RES MF 1.65K 1% 1/4W 144093
R4 RES MF 1.65K 1% 1/4W 144093
R9 RES MF 1K 1% 1/4W 144090
PARTS LIST con’t
MC2KW
POWER
19
5
6A
6B
To Next Page
